This is I believe one of my first posts. I have a guy that brought me an old Troy Bilt tiller. It's got a hh60 on it (Can't remember the spec number) and he tells me it has no power while tilling.
I looked it over and played with the carb on it and when you tap the governor in either direction it stalls the engine. (I was assuming maybe sticking valves at first, but runs to good I think) I did some adjustments to the carb but to no avail, still stalls out when you tap the governor or tries to stall out.
The diagrams I have aren't a good indicator of the carb / governor linkage system on this. I checked the points and all looks fine including the flywheel key. It revs up fine using the carb main fuel needle on the bottom and starts easily on the second pull. Unfortunately I believe these engine are getting harder to get parts for so is it worth it or has anyone seen something like this before?
If I can't get it or anyone knows, I do have a B/S Industrial plus 8hp to throw on it. Any insight on this issue would be great, if you need more info let me know.
Yeah I played with that one to. I believe its running around 3300 rpm right now. Somewheres along the line I had lost my throttle control. So its kinda at one speed even if I move my throttle cable back and forth. If I move the throttle to far it just dies obviously cause of the kill mechanism. I also was just informed that the carb on this unit was replaced once. So im kinda thinking it may not be the right carb or the linkage might be kinda screwy with it.
Like I said before something doesnt look quit right with this set up. Oh well, guess its time to take down the carb and go from there. Know where I can get a descent break down of all the linkages on there? 'chuck thehammer', thats a okey dokey. It took me awhile to find it the first time too.
- H60 & HH60 - 6.0 H.P. TECUMSEH ENGINE. PARTS MANUAL. THIS IS IN GOOD CONDITION! QUICK REFERENCE.
- Engine Specifications and Line Drawings for Tecumseh Small Engines. Service manuals, service information, line drawings and spec sheets, crankshaft drawings for Tecumseh engines.
PartsTree.com - Order Genuine Tecumseh Parts for the Tecumseh HH60-105091F Engines: horizontal 4-cycle engine. Easy Ordering, Fast Shipping and Great.
Don't feel bad. If you back up one page, at the top where you found my post, it says stickey. The very first post. It is in there you will find all the tech manuals. Well ok some of them. Good point 30yeartech, I guess I wasn't looking at that way with linkages, that does make sense.
I'll look for the spec number tonight, it's at my shop right now and im not there. LOL But on the other hand, I do have that manual, it's not enough of what I need to see. If you have that manual downloaded, it's on page 32 - fig. 25 this is what the setup looks like.
I know still need spec number. I'll keep ya posted later tonight.
Ok fellars, here we go. Sorry about the wait. Tecumseh 6 H.P.
HH60 105101F Serial# 6140D Carb # 113 5F12 These are the only numbers I found on the carb. I'm kinda leaning towards 30yearTech's advice.
I pulled the carb apart tonight and wow, what a mess. Alot of carb and choke cleaner in every crevace and hole I could find. Now im gonna let it soak over night and blow her down and see how she looks.
The adjustment screw on the side looks a little dinged up on the end, dont think I can save her. But we will see. I can see why I was having problems with it.
So whats the deal with welch plugs? Never taken one out before.
Are they like an air passage or something. I may need to take them out shes pretty bad.
The adjustment screw on the side looks a little dinged up on the end, dont think I can save her. But we will see. I can see why I was having problems with it.
So whats the deal with welch plugs? Never taken one out before. Are they like an air passage or something. I may need to take them out shes pretty bad.The adjustment screw on the side is for the low speed or idle circuit.
If it's dinged up, then it was installed and tightened down against the metering rod in the low speed port. This rod is supposed to slide up and down in it's chamber. Usually tightening down against the metering rod will deform it and cause it to stick, causing the problems with the idle circuit.
If after you clean it up, you should hear a rattle when you shake the carburetor (without the float installed) if you don't, then the rod is stuck and you will probably need to replace the carburetor to get it to run right. Ohh lala, I got er all cleaned up and the metering rod in the low speed port rattles like the little marble inside my head. Good call 30yeartech.
I reassembled it and that little booger popped off on the second pull. Ok, now for the fun stuff. I touched the governor and she came to life right off the bat, didnt even hesatate when I touched her. But however, while I was trying to move the throttle back and forth, I noticed the RPM's werent changing. So I looked a little deeper and noticed the throttle on the carb wasnt moving. So here I am wondering, my little spring attached to the linkage and carb is way to streched out. It's not even trying to open my throttle.
So I guess im in need of a new spring. Tomorrows episode. The fight with the spring. Thanks guys for the little tips.
1 Tecumseh 34761 'Cylinder (C I liner)(Incl. 2,3,4,184) 2-5/8' Not available 2 Tecumseh 27652 Dowel Pin Your price: $1.85 0 of these in your cart Qty: 3 Tecumseh 27642 Oil Drain Plug (Sq. Hd., 1/4-18) Your price: $1.47 0 of these in your cart Qty: 4 Tecumseh 27876B Seal, Oil Your price: $5.60 0 of these in your cart Qty: 5 Tecumseh 32783 Intake Valve (Std.) (Incl.
9) Your price: $13.57 0 of these in your cart Qty: 5 Tecumseh 32784 Intake Valve (1/32' OS) (Incl. 9) Your price: $58.03 0 of these in your cart Qty: 6 Tecumseh 27878A Exhaust Valve (Std.)(Incl. 151) Your price: $19.27 0 of these in your cart Qty: 6 Tecumseh 27880A Exhaust Valve (1/32' OS) (Incl. 151) Not available 7 Tecumseh 27882 Valve Spring Cap Your price: $1.47 0 of these in your cart Qty: 8 Tecumseh 27881 Valve Spring Your price: $3.05 0 of these in your cart Qty: 9 Tecumseh 32581 Cap, Lower valve spring Your price: $1.47 0 of these in your cart Qty: 11 Tecumseh 31827 Crankshaft (Incl.
Tecumseh Engines
12 & 13) Your price: $168.98 0 of these in your cart Qty: 12 Tecumseh 29783 Pin, Crankshaft gear Used in early pr oduction. This gear is serviceable O NLY when itis pinned to the crankshaf t. Your price: $1.47 0 of these in your cart Qty: 13 Tecumseh 27884 Gear, Crankshaft Used in early produc tion.
Tecumseh Engine Parts Lookup
This gear is serviceable ONLY when itis pinned to the crankshaft. Your price: $9.97 0 of these in your cart Qty: 14 Tecumseh 34503 Piston, Pin & Ring Set (Std.) 2-5/8' Bore Your price: $81.86 0 of these in your cart Qty: 14 Tecumseh 34504 Piston, Pin & Ring Set (.010' OS) Not available 14 Tecumseh 34505 Piston, Pin & Ring Set (.020' OS) Not available 14A Tecumseh 33312B (replaces 31797B) Piston & Pin Ass'y.
Tecumseh Engine Parts
(Std.)(2-5/8') In cl. 16 Not available 14A Tecumseh 31798B Piston & Pin Ass'y. (.010' OS) Incl. 16 Not available 14A Tecumseh 31799B Piston & Pin Ass'y. (.020' OS) Incl. 16 Your price: $64.53 0 of these in your cart Qty: 15 Tecumseh 34854 Ring Set (Std.) (2-5/8' Bore) Not available 15 Tecumseh 34855 Ring Set (.010' OS) Not available 15 Tecumseh 34856 Ring Set (.020' OS) Not available 16 Tecumseh 27888 Piston Pin Retaining Ring Your price: $1.47 0 of these in your cart Qty: 17 Tecumseh 31380C Rod Assy., Connecting (Incl.
